ENGINEERED WOOD

WHY ENGINEERED WOOD?


Durable and long-lasting


Water-resistant and Termite-free


Natural Flame Retardant


Low Maintenance


Free of Toxins


Easy Installation


Natural Look and Feel


Repaintable and Customizable

ENGINEERED WOOD STRUCTURE


TECHNICAL SPECIFICATIONS

Oak
Walnut
Panel Dimension
192x1820/2130mm (+/- 25mm) - nesting rows of half lengths allowed
136x1820/2130mm (+/- 25mm) - nesting rows of half lengths allowed
Overall Thickness
13.5mm
13.5mm
Face (Veneer) Thickness
3.0 +/- 0.2mm
3.0 +/- 0.2mm
Core Thickness
8.5 +/-0.2mm
8.5 +/-0.2mm
Base Thickness
2.0 +/- 0.1mm
2.0 +/- 0.1mm
Rows per pack
6pcs
8pcs
Square Meter per pack
~2.45 m2
~1.98 m2
Face (Veneer) layer
Oak (Origin: Europe)
Walnut(Origin: USA)
Core layer
Pine/Rubber(Origin: New Zealand/Malaysia)
Pine/Rubber(Origin: New Zealand/Malaysia)
Base layer
Eucalyptus/Spruce(Origin: Brazil)
Eucalyptus/Spruce(Origin: Brazil)
Surface Type
Square Edged, Brushed
Square Edged, Matt Lacquer
Tongue & groove
T&G
T&G
Surface Layer Finishing
Matt Lacquer
Matt Lacquer
Surface Layer Grading
AB
Premium/AB
Floating
Underlay (rubber sheet) Ref : Installation instruction
Underlay (rubber sheet) Ref : Installation instruction
Glued to Subfloor
Timber Flooring Glue Ref : Installation instruction
Timber Flooring Glue Ref : Installation instruction
Finishing
UV Curing, 6 layers coating
UV Curing, 6 layers coating
Abrasion Resistance
DIN EN 438-2 (500g load per wheel S 33 ), IP – 120 cycle, FP – 140 cycle ASTM D 4060(500g load per wheel CS 17), IP 6000 cycles
DIN EN 438-2 (500g load per wheel S 33 ), IP – 120 cycle, FP – 140 cycle ASTM D 4060(500g load per wheel CS 17), IP 6000 cycles
Bending: Boards laying on flat surface and measure
Concave (< 5mm, for 1820mm board length type ) Convex (< 12mm, for 1820mm board length type )
Concave (< 5mm, for 1820mm board length type ) Convex (< 12mm, for 1820mm board length type )
Slip resistance
UK SRG, 2000, 82450/11451
UK SRG, 2000, 82450/11451
Emission of Formaldehyde
EN 717-1, E1
EN 717-1, E1
Underfloor heating
Refer to underfloor heating installation instruction
Refer to underfloor heating installation instruction
Reaction to fire
EN 13501-1:2007, DFL-S1
EN 13501-1:2007, DFL-S1
